Brazing
Back in 1973, KYK set up a brazing plant in Hamamatsu, Japan
and started the first commercial brazing process in the Japanese heat treating industry.
The technology accumulated in almost 50 years of KYK's experience is applied to various
type of brazing furnaces and introduced to customers in the form of innovative
hardware and software.

Mesh Belt Aluminum Brazing Furnace

E-MES-NOC

Features
High reliability based on the past delivery record of more than 200 units.
Representing the standard aluminum brazing furances in the industry.
The world first equipment that realized the Nocolok Brazing in a nitrogen atmosphere.
Availble for a small laboratory scale to a mid size production.
  Larger equipment is also available with the OXYNON CAB® furnace model.
Provided for 36 years since the first delivery was made in 1980.
In-house laboratory furnace is available for clients' preliminary study of production
  requirements (feebased).
Main applications
Brazing of aluminum made heat exchangers and functional components.
Main specifications
Maximum Temperature: 620℃
Atmosphere: Nitrogen gas
Capacity: Laboratory scale up to a mid size mass production.

Energy-saving Mesh belt/Roller hearth Brazing Furnace

C-MES-FES
C-ROL-FES

Features
High combustion efficiency burner reduces energy costs.
High efficiency burner also reduces floor space and production costs.
Optimum heat pattern for each product can be set.
Mesh belt or roller hearth can be chosen as the conveyance method.
Main applications
Brazing of ferrous materials, Phosphor copper brazing of copper heat exchangers.
Main specifications
Maximum Temperature: 1100℃
Atmosphere: DX gas
Capacity: Laboratory scale up to a large mass production scale.

Mesh Belt Hump back Brazing Furnace

E-HNP-SUB

Features
The muffle case is protected against heat deformation by use of the top/bottom temperature
  deviation control method.
Reduced gas consumption.
In-house laboratory furnace is available for clients' preliminary study of production
  requirements (fee based).
Main applications
Brazing of ferrous materials.
Stainless steel brazing.
Main specifications
Maximum Temperature: 1130℃
Atmosphere: Hydrogen, Nitrogen
Capacity: Laboratory scale up to a mass production scale.
